? Pitch：8.4mm，Electrical：UL，Rated Voltage：/，Rated Current：/，colour：green ;
? In order to meet the requirements of different application,With and without plastic cover are optional ;
? The products are designed according to IEC60998 and UL1059 international standard and also certified by UL。
→ Pitch：8.4mm
→ Electrical：UL
→ Rated Voltage：/
→ Rated Current：/
→ Wire Diameter Range（AWG/mm2）：20-14/0.5-2.5
→ Operating Temperature Range：-40℃~+105℃
→ Withstand Voltage: /
→ Strip Length：-6-7mm
| Datasheet | |
|---|---|
 |
| Material and Finish | |
|---|---|
| Hosuing | PA66 UL94V-0 |
| Electric conductor | Copper Alloy,Tin-plated |
| Fastening piece Screw/Spring | Steel，Zinc-plated |
| Fastening piece Cage/Nut | Steel |
| Electric Characteristics | UL | IEC |
|---|---|---|
| Rated Voltage | / | 630V |
| Rated Current | / | 15A |
| Withstand Voltage | / | |
| Impulse Withstand Voltage | 6KV | |
| Connection Characteristics | |
|---|---|
| Wire Diameter Range（AWG/mm2) | 20~14/0.5~2.5 |
| Strip Length | 6-7mm |
| Torque | M3,0.5N.m |
| Operating Temperature Range | -40℃~+105℃ |
| Order Number | |
| Package Unit | |
| MOQ | |
Product Weight (Excluding Package) |
